DJI Zenmuse X5S Drone Camera

$2,049.00

This Zenmuse X5S Drone Camera by DJI is designed to keep up with high-end professional aerial imaging with it’s micro 4/3 sensor and a dynamic range.

SKU: CP.ZM.000496 Category: GTIN: 6958265139161

Description

This Zenmuse X5S Drone Camera by DJI is equipped with micro 4/3 sensor and a dynamic range of 12.8 stops that was designed to keep up with high-end professional aerial imaging. This camera supports up to eight standard M4/3 lenses including zoom lenses so that you can use one best for the job. The X5S also supports burst shooting at 20fps with 20.8MP images making it perfect for your aerial missions.

Features

  • Inspire 2 Compatibility
  • Micro 4/3
  • 5.2K CinemaDNG
  • 4K Apple ProRes
  • 12.8 Stops of Dynamic Range
  • 20.8 MP Stills

Additional information

Weight 6 lbs
Dimensions 6 × 6 × 8 in

Specifications

Name Zenmuse X5S
Dimensions 140×98×132 mm
Weight 461 g (Lens Kit)

CAMERA

Supported Lens DJI MFT 15mm/1.7 ASPH (With Balancing Ring and Lens Hood) Panasonic Lumix 15mm/1.7 (With Balancing Ring and Lens Hood) Panasonic Lumix 14-42mm/3.5-5.6 HD Olympus M.Zuiko 12mm/2.0 (With Balancing Ring) Olympus M.Zuiko 17mm/1.8 (With Balancing Ring) Olympus M.Zuiko 25mm/1.8 Olympus M.Zuiko 45mm/1.8 Olympus M.Zuiko 9-18mm/4.0-5.6
Sensor CMOS, 4/3” Effective Pixels: 20.8MP
FOV 72° (with DJI MFT 15mm/1.7 ASPH )
Photo Resolutions 4:3, 5280×3956 16:9, 5280×2970
Video Resolutions Aspect Ratio 17:9 CinemaDNG 4K DCI: 4096×2160 23.976/24/25/29.97p, up to 2.4Gbps; 50/59.94p, up to 4.0Gbps H.264 4K DCI: 4096×2160 23.976/24/25/29.97/47.95/50/59.94p @100Mbps H.265 4K DCI: 4096×2160 23.976/24/25/29.97p @100Mbps Aspect Ratio 16:9 CinemaDNG 4K Ultra HD: 3840×2160 23.976/24/25/29.97p, up to 2.4Gbps; 50/59.94p, up to 4.0Gbps ProRes 4K Ultra HD: 3840×2160 23.976/24/25/29.97p, 422 HQ @900Mbps; 23.976/24/25/29.97p, 4444 XQ @2.0Gbps H.264 4K Ultra HD: 3840×2160 23.976/24/25/29.97/47.95/50/59.94p @100Mbps 2.7K: 2720×1530 23.976/24/25/29.97p @80Mbps; 47.95/50/59.94p @100Mbps FHD: 1920×1080 23.976/24/25/29.97p @60Mbps; 47.95/50/59.94p @80Mbps; 119.88p @100Mbps H.265 4K Ultra HD: 3840×2160 23.976/24/25/29.97p @100Mbps 2.7K: 2720×1530 23.976/24/25/29.97p @65Mbps; 47.95/50/59.94p @80Mbps FHD: 1920×1080 23.976/24/25/29.97p @50Mbps; 47.95/50/59.94p @65Mbps; 119.88p @100Mbps Aspect Ratio 2.44:1 CinemaDNG 5.2K: 5280×2972 23.976/24/25/29.97p, up to 4.2Gbps ProRes 5.2K: 5280×2160 23.976/24/25/29.97p, 422 HQ @1.3Gbps H.264/H.265 4K Ultra HD: 3840×1572 23.976/24/25/29.97p @100Mbps
Photo Formats DNG,JPEG,DNG+JPEG
Video Formats RAW,ProRes,MOV,MP4
Operation Modes Capture, Record, Playback
Still Photography Modes Micro SD: Single shot, Burst Shooting: 3/5/7/10/14 frames, Auto Exposure Bracketing, 3/5 bracketed frames at 0.7EV bias, Interval SSD: RAW Burst Shooting: 3/5/7/10/14/20/∞ frames
Exposure Mode Auto, Manual, Shutter, Aperture
Exposure Compensation ±3.0 (1/3 increments)
Metering Mode Center-weighted metering, Spot metering (area option 12×8)
AE Lock Supported
Electronic Shutter Speed 8-1/8000s
White Balance Auto, Sunny, Cloudy, Incandescent, Neon Custom (2000K–10000K)
ISO Range 100 – 6400 (Video) 100 – 25600 (Stills)
Video Captions Supported
Anti-Flicker Auto, 50Hz, 60Hz
PAL/NTSC Supported

GIMBAL

Angular Vibration Range ±0.01°
Mount Detachable
Controllable Range Tilt: +40° to -130°; Pan: ±320°; Roll: ±20°
Mechanical Range Tilt: +50°to -140°, Pan: ±330°, Roll: +90° to -50°
Max Controllable Speed Tilt: 180° /s; Pan: 270° /s; Roll: 180° /s

ENVIRONMENTAL

Operating Temperature 14°–104°F (-10 to 40℃)
Storage Temperature -4°–140°F (-20 to 60℃)
